This SFP transceiver is high-performance, cost-effective module, designed for 100BASE-FX applications of 2km with Multimode Fibre. The transceiver consists of two sections, the standard SFP part and the PHY part built with SGMII interface.
KEY FEATURES
• Build-in PHY supporting SGMII Interface
• 100BASE-FX operation
• 1310nm FP laser and PIN photo-detector
• 2km transmission with MMF
• Standard serial ID information Compatible with SFPMSA
• SFP MSA package with duplex LC connector
• With Spring-Latch for high density application
• Very low EMI and excellent ESD protection
• +3.3V single power supply
• Operating case temperature: 0 to +70°C
APPLICATIONS
• Switch to Switch interface
• Switched backplane
applications
• Router/Server interface
• Gigabit Ethernet to Fast
Ethernet
• Other optical transmission
systems
