Four-Channel, Pluggable, Parallel, Fibre Optic QSFP+ SR4 for 100 or 40 Gigabit Ethernet and InfiniBand FDR/EDR Applications. This transceiver is a high-performance module for short-range multi-lane data communication and interconnect applications. It integrates four data lanes in each direction with 104 Gbps bandwidth. Each lane can operate at 26Gbps up to 70m using OM3 fibre or 100m using OM4 fibre. These modules are designed to operate over multimode fibre systems using a nominal wavelength of 850nm. The electrical interface uses a 38-contact edge type connector. The optical interface uses a 12 fibre MTP (MPO) connector. This module incorporates Gigalight Technologies proven circuit and VCSEL technology to provide reliable long life, high performance, and consistent service.
KEY FEATURES
• 4 channels full-duplex transceiver modules
• Transmission data rate up to 28.05Gbps per channel
• Compatible with 40GE and 56G FDR data rate
• 4 channels 850nm VCSEL array
• 4 channels PIN photo detector array
• Internal CDR circuits on both receiver and transmitter channels
• Support Electrical or Optical Loopbacks
• Low power consumption <3.5W
• Hot Pluggable QSFP form factor
• Maximum link length of 70m on OM3 Multimode Fibre (MMF)and
100m on OM4 MMF
• Single MPO connector receptacle
• Built-in digital diagnostic functions
• Operating case temperature 0°C to +70°C
• 3.3V power supply voltage
• Duplex LC receptacles
• RoHS 6 compliant (lead free)
APPLICATIONS
• IEEE 802.3bm 100GBASE
SR4 and 40GBASE SR4
• InfiniBand FDR/EDR
• 128G Fibre Channel
• 4x28Gb/s Multimode OTN
