QSFP28 to QSFP28 passive copper cable assembly. High performance, cost effective I/O solution for LAN, HPC and SAN. This high-speed cable assembly, meets and exceed 100 Gigabit Ethernet, Infiniband EFR and temperature requirements for performance and reliability. The cables are compliant with SFF-8436 specifications and provide connectivity between devices using QSFP ports
KEY FEATURES
• Compliant with SFF-8665
• 4-channel full-duplex passive copper cable transceiver
• Support data rates: 27.78Gb/s (per channel)
• Maximum aggregate data rate: 100Gb/s (4 x 25.78Gb/s)
• IEEE 802.3bj 100GEBASE-CR4
• Low crosstalk
• 12C base two-wire serial interface for EEPROM signature which
can be customised
• Compatible to QSFP28 MSA
• RoHS compliant
APPLICATIONS
• 100G Ethernet
